Cino F680 Durable Dropproof 1D Handheld Barcode Scanner PDF417 GS1 Barcode

CMOS, 1D Barcode, 500m/s, 1.8m dropproof, USB HID,USB VCOM,RS232



Model No: F680

Resolution:  ≥3mil

Reading Direction: Bi-directional

Interface: USB HID, USB VCOM, RS232




Product Detail

PARAMETERS

Product Tags

Features

A product of Cino's advanced engineering, the FuzzyScan F680 is a top performer that comes at an affordable price. It quickly captures a wide array of 1D and stacked barcodes, whether they appear on paper, plastic, or digital screens. Durable yet ergonomic, the F680 can withstand drops from a height of 1.8 meters. This linear barcode scanner is ideal for establishments where intensive scanning is the norm.

♦ Faster checkouts
The FuzzyScan F680 reads a vast array of barcodes at lightning speed, whether displayed on paper, plastic, or digital screens. Accelerate the checkout process and get your transactions done in record time. The F680's remarkable performance will keep the lines moving and your shoppers smiling.
handheld barcode scanner

Application

♦ Retail chains

♦ Inventory management

♦ Warehouse and logistics,

♦ Express delivery services and supermarket,

♦ Food traceability

♦ Electricity meter reading

♦ Asset counting


  • Previous:
  • Next:

  • Performance Characteristics
    Optical System High performance linear imaging engine
    Print Contrast 15% minimum reflective difference
    Light Source 630nm LED
    Minimum Resolution 3 mil (Code 39, PCS 0.9)
    Reading Range *1 13 mil (0.33mm) UPC/EAN up to 24”
    20 mil (0.5mm) Code 39 up to 34”
    Scan Rate Dynamic scanning rate up to 500 scans per second
    Reading Direction Bi-directional (forward and backward)
    Pitch / Skew / Tilt ±65˚ / ± 65˚ / ± 55˚
    Host Interfaces USB HID (USB Keyboard)
    USB VCOM (USB COM port emulation)
     Standard RS232
    Configuration Setup Command barcodes
    iCode
    FuzzyScan PowerTool
    Data Editing DataWizard Premium
    Physical Characteristics
    Dimensions 97.0 mm (L) x 65.0 mm (W) x 156 mm (D)
    3.81 in. (L) x 2.55 in. (W) x 6.14 in. (D)
    Weight 125g (cable excluded)
    Color Light Gray or Black
    User Interfaces 3 LEDs for power, good read and status indications
    Programmable beeper
    Optional vibrator
    Operating Voltage 5VDC ± 10%
    Operating Current Operating : Typical 180 mA @5VDC
    Standby : Typical 80 mA @5VDC
    Supported Symbologies
    1D Linear Codes Code 39, Code 39 Full ASCII, Code 32, Code 39 Trioptic
    Code 128, GS1-128, Codabar, Code 11, Code 93
    Standard & Industrial 2 of 5, Interleaved & Matrix 2 of
    5 German Postal Code, China Postal Code, IATA UPC/
    EAN/JAN, UPC/EAN/JAN with Addendum Telepen, MSI/
    Plessey & UK/Plessey
    GS1 DataBar (formerly RSS) Linear & Linear Stacked
    Linear-stacked PDF417, Micro PDF417, Codablock F, Composite
    User Environment
    Drop Specifications Withstands multiple drops from 1.8m (6.0ft) to concrete
    Environmental Sealing IP52
    Operating Temperature -10˚C to 50˚C (14˚F to 122˚F)
    Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
    Humidity 5% to 95% relative humidity, non-condensing
    Ambient Light Immunity 0 ~ 100,000 Lux
    ESD Protection Functional after 15KV discharge
